2002 Contract 3 of the Third-Phase Siltation Promotion and Reclamation Project at Nanhui East Shoal

Project Name	Fujian Quanzhou Fuhai Grain and Oil Reclamation Project
Project Location	South Side of the Dazhi River Estuary, Nanhui	Engineering Costs	RMB 8.3 Million
Start time	September 2002	Completion time	July 2003
Company	Name
Owner	Shanghai Land Formation Co., Ltd.
Designer	Shanghai Water Conservancy Engineering Design & Research Institute
Supervisory	Shanghai Donghua Engineering Supervision Institute
Project Overview
The Shanghai Municipal Government implemented the coastal reclamation project as a major initiative to increase land reserves, covering an area of approximately 50,000 mu (approximately 3,333 hectares). The main dike was designed and constructed to withstand a 50-year return-period storm combined with a Grade 10 typhoon. The dike body was constructed using slurry-filled geotextile tubes, with a bottom width of 50 m, crest width of 6 m, and height of 5 m. On the seaward side, the slope protection consisted of mortar-laid stone facing with concrete block protection. The dike crest was paved with a soil-bound gravel surface, while the inner slope was covered with green grass and landscaping.
